Width	1000 mm
Height	2020 mm
Depth	400 mm
Weight	8.6000 kg

Width	1000 mm
Height	2020 mm
Depth	400 mm
Weight	8.6 kg

Illumigo™ Up

The Illumigo™ Up combines bold LED illumination, vibrant edge-to-edge SEG graphics, and a sleek, frameless design for maximum visual impact. This double-sided, 1 × 2 m LED lightbox ensures visibility from all angles. The pre-assembled scissor frame sets up in minutes, and built-in magnets let you connect multiple units to create striking backwalls. Optional connectors allow for T-shapes or 90-degree angles, perfect for adding dimension to your display. Graphics are easy to swap, so your message can evolve with your brand.

Double-Sided Display: Requires 2 x Graphics

Effortless Setup & Easy Transport

Designed for simplicity, the Illumigo™ Up sets up in just minutes. Just remove it from the compartmentalised carry bag, twist out the feet, and expand the folding frame to full height, then secure it with the horizontal support bar. Built-in magnets make it easy to align multiple units, while optional connectors let you lock in angled arrangements for extra impact.

When it’s time to pack down, everything fits neatly into a compact wheeled carry case, making transport effortless, whether you're rolling into a trade show or heading to your next event.

Add the optional A4 literature holder to keep brochures or printed materials within easy reach, ideal for exhibitions, events, or retail environments.

Single or Double-Sided Display Options

Create stunning visuals with backlit SEG (Silicone Edge Graphics), printed via dye sublimation for exceptional image clarity and vibrant colours, perfect for retail, exhibitions, or any illuminated display.

Each setup, single-sided or double-sided, uses two pieces of fabric: one for the front-facing graphic and one for the rear panel.

Double-Sided Display:

Front & Back: 2 × backlit polyester SEG graphics

This setup delivers your message in both directions, ideal for open spaces and high foot traffic areas where visibility from both sides matters.

Single-Sided Display:

Front: 1 × backlit polyester SEG graphic
Back: 1 × backlit blockout liner, a solid fabric panel on the reverse to block light and focus attention forward

Select Item

Format *

Hardware Only
Graphics Only

Media Type *

Backlit polyester
Backlit Blockout Liner (Non-printed)

Format *

Hardware Only
Graphics Only

Media Type *

Backlit polyester
Backlit Blockout Liner (Non-printed)

Illumigo Up Frame

Free-standing double-sided white aluminium frame, 80 mm profile

Prebuilt folding lightbox with vertical integrated LED lights (4 LED strips)

Internal reinforcement tubes

Pre-assembled twin twist out feet

Power cable located under the frame

Internal magnets allow multiple units to lock together for wider displays

Create T shapes or 90 degree angles with Illumigo Up Connectors, sold separately. Illumigo Up Connectors

Suitable for indoor use only

For Frame and Electrical details see tables below

Installation

Ultra fast assembly - scissor frame extends to full height and is locked in place with the central support rod

Twist out feet

SEG Graphic pushes securely in place into the channel around the edge of the frame

Branded Carry Bag with wheels

Black branded carry bag with foam insert for protection

Carry handle and shoulder straps

Wheels for easy transportation

Illumigo™ Up Lighting Specifications

Technical Details

Component	Specification
Frame	4 × 918 mm LED strips / 72 W (unit)
LED Strip	18 LED lens per strip
Input Power	110/240 V
Output Power	24 V 4.17 A
Kelvin	6500 K
Lumens	2860
Cable Length	3.08 m

Guidelines for Preparing Your Artwork

Nine simple steps to perfect print ready artwork

Artwork saved as pdf. Recommended preset: PDF/X-4:2010. Maximum file size 75MB
Document colour mode is set to CMYK
All fonts are outlined.
Graphics matched to the correct template: centred and in the gross size of the respective template. Please note the template is supplied at 25% of the finished size as the printer RIP will scale it to 100% .
All linked images must have a minimum resolution of 300 dpi at 1/4 (25%) scale.
The print file should not contain template lines.
Letter size not less than 3mm ; 2mm for lines
Disabled overprint attribute.
Recommended values for black: C100, M100, Y100, K100

PSS_ILLUMIGO_UP_EN

Download Product Images

Illumigo™ Up Product images

Watch the video

}

Product specifications

Attribute name	Attribute value
Product Specifications
Material	Aluminium
Profile width	80mm
Profile Colour	White
Assembly	Tool less
Graphic area	Double-sided
Graphic attachment	Silicone Edged Gasket 3 mm (SEG)
Application	Self-supporting with pivoting feet fixed to the structure
Transport	Wheeled carry bag

We are continually improving and modifying our product range and reserve the right to vary the specifications without prior notice. All dimensions and weights quoted are approximate and we accept no responsibility for variance. E&OE.
