Ultima Displays. Illumigo Modular 2380mm H Lightbox System

Width	1850 mm
Height	2389 mm
Depth	590 mm
Weight	22.7000 kg

Width	2850 mm
Height	2389 mm
Depth	590 mm
Weight	29.1000 kg

Width	3850 mm
Height	2389 mm
Depth	590 mm
Weight	36.8000 kg

Width	4850 mm
Height	2389 mm
Depth	590 mm
Weight	45.1000 kg

Width	5850 mm
Height	2389 mm
Depth	590 mm
Weight	51.6000 kg

Frames

120mm Profile Depth

White powder coated aluminium profile with pre-fitted horizontal LEDs

Expandable up to 7.85M (1 x 5.85M Frame & 2 x 1M Extension)

Feet supplied (quantity varies per size)

Power Cable Details

Plug to transformer: 1790mm / Transformer to hardware: 1655mm

For Frame and Electrical details see tables below

Installation

Numbered sections with pre-installed LEDs push fit together

Feet push in place and are held in place with thumbscrews

SEG Graphic pushes securely in place into the channel around the edge of the frame

Branded Carry Back with wheels

Black branded carry bag with foam insert for protection

Carry handle and shoulder straps

Wheels for easy transportation

Suitable for indoor use only

Illumigo™ Modular Frames & Extensions

Illumigo™ Modular Frame Sizes

Width	Height	SKU Code	Feet	Rods	Cross	Brackets	Transformers	Weight (kg)
1850mm	2380mm	ILLGO-MOD-1824	3	4	1	8	1	22.7
2850mm	2380mm	ILLGO-MOD-2824	4	7	2	10	1	29.1
3850mm	2380mm	ILLGO-MOD-3824	5	10	3	12	2	36.8
4850mm	2380mm	ILLGO-MOD-4824	6	13	4	14	4	45.1
5850mm	2380mm	ILLGO-MOD-5824	7	16	5	16	4	51.6

Illumigo™ Extensions

Width	Height	SKU Code	Feet	Rods	Cross	Brackets	Transformers	Weight (kg)
850mm	2380mm	ILLGO-MOD-EXT-0824	1	2	1	2	0	6.45
1000mm	2380mm	ILLGO-MOD-EXT-1024	1	2	1	2	0	7

Illumigo™ Modular Lighting Specification

Shared Lighting Specifications

Input Power:	100–240V / 50–60Hz / 3.5A
Output Power:	24V / 11A
Kelvin:	6500K

Frame-Specific Lighting Output

Frame Size	Lumens	Watts
1824	2.7	168
2824	4.14	258
3824	5.58	348
4824	7.02	437
5824	8.46	528

Illumigo™ Modular Accessories

Illumigo™ Modular Accessories

Sku Code	Product	Link
ILLGO-90TC	90° Connector (unit)	View Product
ILLGO-TC	T Connector (unit)	View Product
ILLGO-MOD-90MIC	M Connector (x4)	View Product
ILLGO-LH-A4	A4 Holder (unit)	View Product
ILLGO-MOD-BF	Blank Foot (unit)	View Product
ILLGO-MOD-HF	Half Foot (unit)	View Product
ILLGO-MOD-DRIVER	Transformer (unit)	View Product

Illumigo™ Modular Box Weight and Dimensions

Illumigo™ Modular Box Weight and Dimensions for shipping

Sku Code	No. of Boxes	Packaging: Box 1				Packaging: Box 2
		Weight (Kg)	Width (mm)	Height (mm)	Depth (mm)	Weight (Kg)	Width (mm)	Height (mm)	Depth (mm)
ILLGO-MOD-1824	1	24.8	1450	175	450
ILLGO-MOD-2824	1	31.31	1450	175	500
ILLGO-MOD-3824	2	20.65	1450	175	450	20.1	1360	175	450
ILLGO-MOD-4824	2	22.35	1450	175	450	26.65	1360	175	450
ILLGO-MOD-5824	2	26.5	1450	175	450	28.85	2145	175	450
ILLGO-MOD-EXT-0824	1	7.7	1280	170	230
ILLGO-MOD-EXT-1024	1	8.15	1280	180	235

Product specifications

Attribute name	Attribute value
Product Specifications
Material	Aluminium
Profile width	120mm
Profile Colour	White
Assembly	Tool less
Graphic area	Double-sided
Graphic attachment	Silicone Edged Gasket 3 mm (SEG)
Application	Self-supporting
Transport	Wheeled carry bag

We are continually improving and modifying our product range and reserve the right to vary the specifications without prior notice. All dimensions and weights quoted are approximate and we accept no responsibility for variance. E&OE.
